CASE STUDY · BEVERAGE

Water producer automates bottling from 200 ml to 2 litres on a 3-in-1 line

A South African beverage producer needed one automated line to bottle water in sizes from 200 ml to 2 litres. We supplied a 3-in-1 rinsing, filling and capping machine with a dryer, a labeller, a sleeve sealer shrink wrapper and connecting conveyors, specified for up to 30 bottles a minute.

3-in-1 bottle rinsing, filling and capping machine
3-in-1 rinsing, filling and capping machine
INDUSTRY
Beverage
PRODUCT
Bottled water
BOTTLE SIZES
200 ml to 2 litres
OUTPUT
Up to 30 bottles a minute
MACHINE SUPPLIED
THE CUSTOMER

What the customer bottles

The customer produces bottled water in a range of sizes, from 200 ml up to 2 litres, and shrink wraps some products into multipacks. Production was growing, and bottling had to keep pace without a separate standalone machine for every step.

Complete Bottling System
THE BRIEF

What the bottling line had to do

The customer wanted a complete line in which every machine works with the next, rather than separate standalone machines.

01

Every step in one line

Rinsing, filling, capping, drying, labelling and shrink wrapping had to run as one line.

02

A wide bottle range

The line had to fill accurately across bottles from 200 ml to 2 litres.

03

Up to 30 bottles a minute

Output had to reach 30 bottles a minute, with conveyors linking each machine.

THE MACHINE

The line we supplied: 3-in-1 water bottling line

The line centres on a 3-in-1 machine that rinses, fills and caps in one frame, with 8 rinsing heads, 8 filling heads and 3 capping heads. Empty bottles arrive on an air conveyor that carries them by the neck through a fan-fed tunnel, so dust stays out before filling. Downstream, a dryer prepares the bottles for labelling, an automatic round-bottle labeller applies the labels and a sleeve sealer shrink wraps multipacks, with conveyors linking every machine.

3-in-1 rinsing, filling and capping machine

Bottles are rinsed, filled and capped in one machine before they move on to drying, labelling and shrink wrapping.

SPECIFIED FOR THIS LINE
Core machine3-in-1 rinse, fill and cap
Heads8 rinsing, 8 filling, 3 capping
Filling volume200 ml to 2 litres
Bottle size50 to 110 mm diameter, 150 to 310 mm tall
Output30 bottles a minute at 500 ml
InfeedAir conveyor, 20 to 60 bottles a minute
LabellerRound bottles, 25 to 40 a minute, ±1 mm
DownstreamDryer, labeller, sleeve sealer shrink wrapper
ConveyorsLinking every machine
HOW THE MACHINE WAS SPECIFIED

How the line was specified

The line was sized from the customer's bottle range and target output before anything was ordered.

01

Bottle range

We reviewed the bottle sizes, from 200 ml to 2 litres.

02

Target output

The required speed was set at 30 bottles a minute.

03

3-in-1 set-up

The rinsing, filling and capping configuration was chosen to suit.

04

Downstream machines

A dryer, labeller and sleeve sealer shrink wrapper were matched to the 3-in-1.

05

Layout

Conveyors and the line layout were planned so bottles flow from one machine to the next.

THE RESULT

What changed after installation

The complete line has been installed and commissioned, with rinsing, filling, capping, drying, labelling and shrink wrapping in one automated process.

30
BOTTLES A MINUTE

Specified for up to 30 a minute

Output was set at up to 30 bottles a minute across the bottle range.

200 ml–2 L
BOTTLE RANGE

One line for every bottle size

Sizes from 200 ml to 2 litres run on the same line.

1
COMPLETE LINE

From empty bottle to multipack

Rinsing through to shrink wrapping runs as one connected line.
