A hardware packer needed to shrink wrap stacks of five grinding discs with a paper card on top, as neat and stable retail packs. We configured an L-bar shrink wrap machine from the measured stack and card sizes, and it now wraps each stack and card cleanly as one pack.
The customer packs hardware and abrasive products for retail. Grinding discs are sold in stacks of five with a paper card on top, so the film has to hold the discs and the card together as one stable pack that looks neat on the shelf. Production was growing, and the customer also wanted a packing step it could automate further later.
A stack of discs with a loose card on top has to be wrapped tightly enough to stay together without spoiling how it looks.
Each stack of five grinding discs and its paper card had to be grouped and wrapped together.
The shrink-wrapped stack had to stay stable and look professional on a retail shelf.
The packing step had to suit automation upgrades the customer was planning.
We recommended an L-bar shrink wrap machine because it wraps a grouped stack of grinding discs and the paper card in one pack, with a clean, consistent seal. It handles the stack and card together and keeps the pack stable for retail.
The stack and card are placed in centre-fold film, and the L-shaped sealing bar seals and cuts the film around them, ready for shrinking.
| Machine | SAP-450 L-bar shrink wrap machine |
| Product | Stacks of five grinding discs |
| Insert | Paper card on top of each stack |
| Maximum sealing length | 500 mm |
| Maximum product size | 330 × 125 mm |
| Configured from | Product images and measured stack and card sizes |
Model codes shown are machines we have supplied and configured for previous projects. Your machine is specified and configured to suit your product, output and pack format — not supplied off the shelf.
The L-bar shrink wrap machine was configured from the customer’s own stack and card sizes before it was supplied.
We went through images of the grinding disc stacks and the pack the customer wanted.
The stack of five discs and the paper card were measured.
The machine configuration was confirmed for those sizes.
We presented the recommended setup to the customer.
The customer approved the setup and bought the machine.
After installation, the customer wraps its grinding disc stacks reliably and more efficiently than by hand, and said it was satisfied with the machine. It is now considering an automatic counting and stacking system for the discs.
Grinding disc stacks are shrink wrapped reliably with the card in place.
Pack neatness and retail presentation improved.
Packing is more consistent and more efficient than the manual method.
The clip shows an L-bar shrink wrap machine like the one supplied. The playlist shows more L-bar applications.
